分体T型金属多孔电缆防水接头

广东佳业新能源科技有限公司

咨询热线：18925858265

公司网站：jarye88.com

产品材质：A、C、F部位以黄铜镀镍/不锈钢/铝合金制成，部分以UL认可之尼龙PA66制成（可防火等级UL94V-2），B及D部分采用硅橡胶制成（可定制EPDM耐候橡胶）

螺牙规格：公制牙（Metric)、G（PF）牙、PG牙及NPT牙

工作温度：-40°C至100°C

产品特性：特殊夹紧爪与夹紧圈凹凸相扣之设计，配合迫紧头装配省时省力，夹紧电缆的范围大、抗拉力强、可防水、防尘、抗盐、耐盐酸、酒精、油脂及一般溶剂

多样出孔：有多个孔电源、电缆专用之出线设计，使每一个别之电缆得到最佳之防水绝缘效果，且不致相互纠缠

Guangdong Jiaye New Energy Technology Co., Ltd

Consultation hotline: 18925858265

Company website: jarye88.com

Product Material: Parts A, C, and F are made of brass nickel plated/stainless steel/aluminum alloy, some are made of UL approved nylon PA66 (fire resistance level UL94V-2), parts B and D are made of silicone rubber (EPDM weather resistant rubber can be customized)

Screw specifications: metric, G (PF), PG, and NPT teeth

Working temperature: -40 ° C to 100 ° C

Product features: Special clamping claw and clamping ring with concave convex interlocking design, combined with tightening head assembly to save time and effort. The clamping range of the cable is large, with strong tensile resistance, waterproof, dustproof, salt resistant, resistant to hydrochloric acid, alcohol, grease, and general solvents

Multiple outlets: With multiple outlets for power supply and cables, each individual cable has the best waterproof and insulation effect without entanglement

金属防水T型多孔接头铜镀镍防水接头

公制螺纹M系列
