分体T型金属电缆防水接头

广东佳业新能源科技有限公司

咨询热线：18925858265

公司网站：jarye88.com

产品材质：接头A、C、F部位采用黄铜镀镍/不锈钢/铝合金制成，夹紧件采用尼龙塑料（PA）制成，密封件和O型密封圈采用丁腈橡胶（NBR）/硅橡胶制成

产品认证：欧洲CE认证、欧洲ROHS认证、欧洲REACH认证

螺牙规格：德制螺纹PG系列，符合欧盟规范

螺纹长度：短螺纹适合用于薄型机板的开孔或附有内螺纹的设备上，长螺纹适合接合厚型机板。螺纹加长型可定制

产品特性：特殊夹紧爪与夹紧圈凹凸相扣之设计，配合迫紧头装配省时省力，夹紧电缆的范围大、抗拉力强、可防水、防尘、抗盐、耐盐酸、酒精、油脂及一般溶剂

防护等级：在规定的卡口范围内，并使用O型密封圈旋紧迫紧头，达到IP68-10巴压力

工作温度：静态：-40°C到100°C，短时间达120°C。动态：-20°C到80°C，短时间达100°C

使用方法：金属电缆防水接头是电缆的配套产品，接头可将电缆锁紧，另一端可接入设备箱体上，也可以根据螺纹接入进出口为内螺纹的电动设备上

更多选择：可根据客户实际需要，特别定制。需要订购时欢迎来电咨询

Guangdong Jiaye New Energy Technology Co., Ltd

Consultation hotline: 18925858265

Company website: jarye88.com

Product Material: The joints A, C, and F are made of brass nickel plated/stainless steel/aluminum alloy, the clamping parts are made of nylon plastic (PA), and the sealing parts and O-ring are made of nitrile rubber (NBR)/silicone rubber

Product certification: European CE certification, European ROHS certification, European REACH certification

Screw thread specification: German made thread PG series, in compliance with EU standards

Thread length: Short threads are suitable for opening holes in thin machine boards or equipment with internal threads, while long threads are suitable for joining thick machine boards. Customizable thread extension type

Product features: Special clamping claw and clamping ring with concave convex interlocking design, combined with tightening head assembly to save time and effort. The clamping range of the cable is large, with strong tensile resistance, waterproof, dustproof, salt resistant, resistant to hydrochloric acid, alcohol, grease, and general solvents

Protection level: Within the specified bayonet range, use an O-ring to tighten the tightening head and achieve a pressure of IP68-10 bar

Working temperature: Static: -40 ° C to 100 ° C, up to 120 ° C in a short period of time. Dynamic: -20 ° C to 80 ° C, reaching 100 ° C in a short period of time

Usage: Metal cable waterproof joint is a matching product of the cable. The joint can lock the cable tightly, and the other end can be connected to the equipment box. It can also be connected to electric equipment with internal threads at the inlet and outlet according to the thread

More options: Customized according to the actual needs of customers. When you need to place an order, please feel free to inquire by phone

金属防水T型接头铜镀镍防水接头

公制螺纹M系列
