防折弯金属电缆防水接头

广东佳业新能源科技有限公司

咨询热线：18925858265

公司网站：jarye88.com

产品材质：接头主体部位采用黄铜镀镍制成，夹紧件采用尼龙塑料（PA）制成，密封件和O型密封圈均采用丁腈橡胶（NBR）制成

螺牙规格：公制牙M（Metric）系列，符合欧盟规范

防护等级：在规定的卡口范围内，并使用O型密封圈旋紧迫紧头，达到IP68-10巴压力

工作温度：静态：-40°C到100°C，短时间达120°C。动态：-20°C到80°C，短时间达100°C

螺纹长度：短螺纹适合用于薄型机板的开孔或附有内螺纹的设备上，长螺纹适合接合厚型机板。螺纹加长型可定制。

产品特性：本产品经特殊设计，将电缆穿入本固定头时，可利用固定头上附加弹簧结构保护电缆不受弯曲而造成损伤，可延长电缆寿命及增加安全性，并且扎实的提供防水防尘IP68保护与固定抗拉力效果

更多选择：可根据客户实际需要，特别定制。需要订购时欢迎来电咨询

Guangdong Jiaye New Energy Technology Co., Ltd

Consultation hotline: 18925858265

Company website: jarye88.com

Product Material: The main body of the joint is made of brass nickel plating, the clamping part is made of nylon plastic (PA), and the sealing part and O-ring are both made of nitrile rubber (NBR)

Screw specifications: Metric series, in compliance with EU regulations

Protection level: Within the specified bayonet range, use an O-ring to tighten the tightening head and achieve a pressure of IP68-10 bar

Working temperature: Static: -40 ° C to 100 ° C, up to 120 ° C in a short period of time. Dynamic: -20 ° C to 80 ° C, reaching 100 ° C in a short period of time

Thread length: Short threads are suitable for opening holes in thin machine boards or equipment with internal threads, while long threads are suitable for joining thick machine boards. The thread extension type can be customized.

Product features: This product is specially designed to use an additional spring structure on the fixed head to protect the cable from bending and damage when the cable is threaded into the fixed head. It can extend the cable life and increase safety, and provide solid waterproof and dustproof IP68 protection and fixed tensile resistance

More options: Customized according to the actual needs of customers. When you need to place an order, please feel free to inquire by phone

防折弯金属电缆防水接头

公制螺纹M系列
