金属T型防水透气一体式接头透气阀

广东佳业新能源科技有限公司

咨询热线：18925858265

公司网站：jarye88.com

产品材质:A.C.F部分采用UL认可之尼龙PA66(防火等级UL94V-2/黄铜镀镍制成(可定制UL认可的V-0防火等级尼龙原料;B.D部分采用优质耐候橡胶制成。(可定制耐寒、耐高温橡胶;耐高酸碱、耐化学与抗腐蚀橡胶)。欧洲CE认证、欧洲ROHS认证、欧洲REACH认证颜色:尼龙可定制黑色、灰色、(特殊颜色可定做)，黄铜镀镍为亮银色工作温度:静态:-30C到200°C，短时间达220C。

螺纹长度:短螺纹适合用于薄型机板的开孔或附有内螺纹的设备上，长螺纹适合接合厚型机板。螺纹加长型可定制。保护等级:IP68-10

产品特性:呼吸电缆防水接头产品开发的灵感来自于大自然。通过使用有效平衡呼吸的聚四氣乙烯(ePTFE)膜可持续保持设备内部和外部压力平衡从而最大程度上避免了冷凝水的形成，完成对电器设备的防护

使用方法:呼吸电缆防水接头是电缆的配套产品，接头可将电缆锁紧，另一端可接入设备箱体上，也可以根据选用螺纹接入进出口为内螺纹的电动设备

产品特性:

1.具有透气功能的电缆防水接头，防水锁线和透气功能同步实现。

2.持续平衡壳体内外的压力，来防止压力积聚,从而延长密封壳 体使用寿命，保护敏感的电子、电器产品，降低电器元件损坏的风险

3.通过更有效的水汽扩散使凝露降至最少;

4.防止灰尘、污垢和碎屑等污染物进入密封壳体内部:

5.通用件且安装简易(非标产品可定制);

Guangdong Jiaye New Energy Technology Co., Ltd

Consultation hotline: 18925858265

Company website: jarye88.com

Product Material: A C. Part F is made of UL approved nylon PA66 (fire rating UL94V-2/brass nickel plated), which can be customized with UL approved V-0 fire rating nylon raw materials. Part B and D are made of high-quality weather resistant rubber, which can be customized with cold and high temperature resistant rubber, high acid and alkali resistance, chemical resistance, and corrosion resistance rubber. European CE certification, European ROHS certification, European REACH certification Color: Nylon can be customized in black, gray (special colors can be customized), brass nickel plated in bright silver Working temperature: Static: -30 ° C to 200 ° C, up to 220 ° C in a short time.

Thread length: Short threads are suitable for opening holes in thin machine boards or equipment with internal threads, while long threads are suitable for joining thick machine boards. The thread extension type can be customized. Protection level: IP68-10

Product features: The inspiration for the development of waterproof connectors for breathing cables comes from nature. By using an effectively balanced breathing polytetraethylene (ePTFE) film, the internal and external pressure balance of the equipment can be sustainably maintained, thereby minimizing the formation of condensate and completing the protection of electrical equipment

Usage: The waterproof joint of the breathing cable is a matching product of the cable. The joint can lock the cable tightly, and the other end can be connected to the equipment box. It can also be connected to electric equipment with internal threads at the inlet and outlet according to the selection of threads

Product features;

1. Cable waterproof joints with breathable function, synchronized with waterproof locking wire and breathable function.

2. Continuously balance the pressure inside and outside the housing to prevent pressure accumulation, thereby extending the service life of the sealed housing, protecting sensitive electronic and electrical products, and reducing the risk of damage to electrical components

3. Minimize condensation through more effective water vapor diffusion;

4. Prevent pollutants such as dust, dirt, and debris from entering the interior of the sealed housing;

5. Universal components and easy installation (non-standard products can be customized);
